Description
Mixing THE RUGGEDNESS AND Longevity Of THE KING COBRA Using The High End OPTIONS From The KING COBRA VENOM
The KING COBRA HYBRID shaker combines
trustworthy KING COBRA standard skid, back tank, and screen position adjustment
features using the rugged new KING COBRA VENOM shaker basket. The basket’s
patented Contour Plus™ design
cuts down on the liquid pool depth to supply better conveyance of drilled solids
over the screens. Configured for 0° in the feed panel and +5° around the
remaining panels, the Contour Plus
design minimizes basket position elevation and achieves drier solids and elevated
screen existence by reducing the dirt pool volume weight within the screens.
We’ve also outfitted the KING COBRA
HYBRID with a number of high end options* like our patented CONSTANT-G
CONTROL™ (CGC) for elevated process capacity and dual motion for additional precise
vibration control.
Using the rugged longevity of the
KING COBRA and also the fine-tuned performance options from the KING COBRA VENOM, the
KING COBRA HYBRID has got the versatility to satisfy your operation’s altering needs.
*All high end options can
be purchased initially or set up in the area no matter original factory
configuration.
Features/Benefits
FEATURES
BENEFITS
Minimal
substitute parts
Small parts
inventory
Straight line motion
(on all configurations)
Quickly
separates and discharges solids
G-Pressure
Fixed nominal
• 6.1
G’s – 2.5 hp
• 8.
G’s – 3.5 hp
CONSTANT-G CONTROL –
patented
worldwide:
•
Instantly – sustained settings as loading increases or decreases
• 6.3
G optimal – 2.5 hp motors
• 7.3
-8.3 G optimal – 3.5 hp motors
Patented CONTOUR
PLUS deck design with incorporated drying deck. Deck angles (0°, +5°, +5°, +5°).
Increases screen existence by diminishing dirt pool
volume and reduces dirt losses using a dry solids discharge
VENOM series
screens
• Bigger
screening area (33.4 ft2 or 3.1 m2)
• Cost saving
with removal of crown rubbers
• Repairable
screens
• Improved
cuttings conveyance and fluid throughput
Patented pin and
hole screen securing system
Screen guaranteed
snugly to basket without any sliding
Manual Flywheel
deck position adjustment mechanism
Fast and simple
deck position adjustments
Epoxy and glass
flake paint system
Longer paint
existence
Specifications
Dimensions (L x W x H)
120 in x 67.7 in x 65.5 in (3048 mm x 1720 mm x 1664 mm)
Weir Height
41 3/16 in (1046 mm)
Weight
5300 lbs (2404 kg)
Basket Position
Adjustable -5° to +3°
Deck
Position
0°,
+5°, +5°, +5°
Screening Area
33.4 foot? (3.1m?)
Screen Type (qty 4)
Pretension, Repairable
Drive Motor
• 2.5 hp (1.9 kw) Standard
• 3.5 hp (2.6kw) Optional
Vibration Motion
Straight line or Dual
Other
Vibration Motion
Straight line or Dual
Dual Motion
Configuration
• Enables
choice of vibration motion most appropriate
– Straight line – Quickly separates and
discharges solids
– Tuned Elliptical – Removes large,
sticky, hydrated clays along with other
–
difficult solids
Motors
• 2.5 hp Standard
• 3.5 hp Optional
Adjustable
Basket Hood
Helps you to contain
splashing during operation and results in a cleaner course
